Pixels Per Inch

323 ppi

Image Control

Anamorphic De-Squeeze, False Color, Focus Assist, Focus Peaking, Histogram, Image Flip, Image Rotate, Pixel Zoom, Pixel-to-Pixel Zoom, RGB Parade, Scaling, Vectorscope, Waveform, Zebra

Audio Input & Output

1x 1/8" / 3.5 mm Headphone Output

Embedded Audio

HDMI
SDI

Video Format

HDMI (10-Bit 4:4:4 RGB, YCC)
UHD 4K: 30/29.97/24/23.98
1080p: 60/59.94/50/30/29.97/25/24/23.98
1080i: 120/119.88/100/60/59.94/50
720p: 120/119.88/100/60/59.94/50/30/29.97/25/24/23.98
576p: 200/100/50
480p: 240/239.76/120/119.88/100/60/59.94
480i: 240/239.76/120/119.88/100/60/59.94
576i: 200/100/50
SDI (10-Bit 4:2:2 YCC)
1080p: 60/59.94/50/30/29.97/25/24/23.98
1080i: 60/59.94/50
720p: 60/59.94/50
576p: 50/25
480p: 60
576i: 50
480i: 59.94

Mount

4x 1/4"-20 Female

Media Slot

Single Slot: SD/SDHC/SDXC

Battery Type

2x L-Series (interchangeable mount)

Power Input & Output

1x Barrel (10 VDC) Input

Other Input & Output

1x Micro-USB 2.0 Input

Wi-Fi Compatibility

No

Bluetooth Compatibility

No

Material

Aluminum

Input Power

10 - 34 VDC

Dimensions

7.09 x 4.67 x 1.32" / 18.01 x 11.86 x 3.35 cm

Weight

26.00 oz / 737.00 g
