Display Resolution

1920 x 1200

Video Input & Output

3x BNC (12G-SDI) Output
1x BNC (3G-SDI) Monitor Output

Touchscreen

Yes

Pixels Per Inch

322 ppi

Audio Recording

2-Channel 24-Bit 48 kHz

Battery Chemistry

Lithium-Ion

Battery Capacity

156 Wh

Storage Capacity

2000 GB

Card Type

CFexpress Type B

Read Speed

1785 MB/s (maximum)
1785 MB/s (sustained)

Write Speed

1550 MB/s (maximum)
1300 MB/s (sustained)

Bus Type

PCI-Express 3.0

Power Source

AC Power (Cable Included)

Audio Input & Output

1x LEMO 5-Pin Mic/Line (+48 V Phantom Power) Input
1x 1/8" / 3.5 mm TRS Stereo Headphone Output

Connector 1

1x Proprietary

Connector 2

1x Proprietary

Rod Standard

15 mm LWS / 60 mm Spacing

Mount

2x 1/4"-20 Female

Tripod Mount

3x 1/4"-20 Female (bottom)
3x 3/8"-16 Female (bottom)

Shoe Mount

None

Rail Mount

None

Accessory Mount

16x 1/4"-20

Rod Compatibility

2x 15 mm Rod Port

Media Slot

1x CFexpress Type B (CFexpress 2.0, PCIe 3.0 x4)

Battery Mount

Gold Mount

Battery Type

Gold Mount

Charger Compatibility

Gold Mount / RED REDVOLT / RED REDVOLT XL

Attachment Method

2x Included 1/4"-20 Screw

Compatibility

USB-C Male [3.2 Gen 2x2 (20 Gb/s)]

Power Input & Output

1x IEC Female Input
• 100 to 240 VAC, 50 / 60 Hz

Other Input & Output

1x USB-C Control/Data/Video
1x 9-Pin (Gigabit Ethernet) Control/Data Input/Output
1x LEMO 4-Pin (RS-232) Control

Wireless Control

2.4 / 5 GHz Wi-Fi Control

Material

Aluminum

Included Adapters & Cables

1x USA Type-A/B Plug to IEC Male Cable

Output Voltage

12 VDC
24 VDC

Dimensions

5.5 x 4.5 x 3" / 139.7 x 114.3 x 76.2 mm

Weight

7.99 lb / 3.62 kg
