Display Resolution

1920 x 1200

Video Input & Output

2x BNC (12G-SDI) Output

Touchscreen

Yes

Pixels Per Inch

322 ppi

Audio Recording

2-Channel 24-Bit 48 kHz

Power Source

Camera

Audio Input & Output

1x LEMO 5-Pin Mic/Line (+48 V Phantom Power) Input
1x 1/8" / 3.5 mm TRS Stereo Headphone Output

Rod Standard

15 mm LWS / 60 mm Spacing

Mount

2x 1/4"-20 Female

Camera Compatibility

RED V-RAPTOR

Camera Mount

Arca-Type Plate with 3/8"-16 Male Screw

Tripod Mount

Dovetail Plate
1/4"-20 Female Thread
3/8"-16 Female Thread

Shoe Mount

None

Accessory Mount

28x 1/4"-20

Rod Compatibility

2x 15 mm Rod Port (baseplate, front)

Media Slot

Single Slot: CFexpress Type B (CFast 2.0)

Battery Mount

Gold Mount

Battery Type

Micro V-Mount

Battery Plate

None

Compatibility

RED DSMC3 V-RAPTOR

Input & Output

1x D-Tap
2x LEMO 2-Pin

Input

Gold Mount: 11 to 17 VDC

Power Input & Output

1x LEMO 6-Pin (11 to 17VDC) Input

Other Input & Output

1x USB-C Control/Data/Video
1x 9-Pin Control/Data Input/Output

Wireless Control

2.4 / 5 GHz Wi-Fi Video Output

Material

Aluminum

Dimensions

6.1 x 4.3 x 4.3" / 155.5 x 108 x 108 mm

Weight

4 lb / 1.8 kg
