PORTKEYS BM5 III WR 5.5" HDMI Touchscreen Monitor with Camera Control

Pixels Per Inch

401 ppi

Image Control

Anamorphic De-Squeeze, Check Field, False Color, Focus Peaking, Histogram, Image Flip, Image Rotate, RGB Parade, Screen Markers, Underscan, Waveform

Audio Input & Output

No

Embedded Audio

SDI
HDMI

Material

Aluminum

Video Format

HDMI (10-Bit)
1080p: 60/59.94/50/30/29.97/25/24/23.98
1080PsF: 30/29.97/25/24/23.98
1080i: 60/59.94/50
720p: 60/59.94/50
576p: 50
576i: 50
480p: 60/59.94
480i: 60/59.94
SDI (10-Bit 4:4:4/4:2:2 RGB, YUV)
1080p: 60/59.94/50/30/25/24/23.98
1080i: 60/59.94/50
720p: 60/59.94/50

Mount

1x 1/4"-20 Female

Power Input & Output

1x Unspecified 4-Pin (24 VDC) Input
1x Unspecified 4-Pin (7.4 VDC) Output

Other Input & Output

1x USB-A 2.0
1x USB-B 2.0
1x Proprietary

Wi-Fi Compatibility

No

Bluetooth Compatibility

No

Input Power

7.4 to 24 VDC

Dimensions

5.7 x 4.8 x 1.8" / 145.4 x 120.9 x 45.5 mm

Weight

13.3 oz / 376 g
