Audio Input & Output

Receiver: 1x 1/8" / 3.5 mm Headphone Output

Embedded Audio

HDMI/SDI

Latency

68 ms

Maximum Range

3.7 Miles / 6 km (Line-of-Sight)

Resistance

None

Video Format

HDMI/SDI (10-Bit 4:2:2 YCC)
1080p: 60/59.94/50/30/25/24/23.98
1080i: 60/59.94/50
720p: 60/59.94/50

Mount

Cold Shoe (transmitter, bottom)

Media Slot

Single Slot: SD/SDHC/SDXC [Supports Recording]

Battery Type

1x L-Series (transmitter/receiver, interchangeable mount)

Power Input & Output

Transmitter/Receiver: 1x Barrel Input

Other Input & Output

Receiver: 1x USB-C 2.0 Input

Wi-Fi Compatibility

Wi-Fi 5 (802.11ac); Dual-Band (2.4 & 5 GHz)

Bluetooth Compatibility

No

Input Power

6 - 18 VDC

Dimensions

Transmitter: 5 x 3.4 x 1" / 127 x 87 x 26 mm
Receiver: 8.4 x 5.3 x 2" / 213 x 135 x 51 mm

Weight

Transmitter: 12.35 oz / 350.00 g, Excluding Antenna
Receiver: 1.60 lb / 727.00 g, Excluding Antenna
