Load Capacity

2.1 lb / 960 g

Rotation Range

Controllable Range
Yaw (Pan): 285°
Roll: 70° (-35 to 35°)
Pitch (Tilt): 210° (-55 to 155°)
Mechanical Range
Yaw (Pan): 330°
Roll: 320° (-90 to 230°)
Pitch (Tilt): 250° (-75 to 175°)

Media Slot

Single Slot: CFexpress Type B (Supports Optional DJI ProSSD Module, 1 TB maximum)

Battery Type

DJI TB50

Power Input & Output

1x Barrel (12 to 30VDC) Input

Other Input & Output

1x USB-C (USB 3.2 / 3.1 Gen 1) Data/Video Input/Output
1x Proprietary Monitor Output

Wireless Control

Wi-Fi

Material

Aluminum, Carbon Fiber, Magnesium Alloy

Dimensions

12.2 x 11.4 x 10.9" / 309 x 290 x 277 mm (With Protrusions)
9.3 x 6.3 x 4.5" / 235 x 160 x 115 mm (without protrusions)

Weight

10.3 lb / 4.67 kg (with battery, Grip, Handle, Monitor, media, Viewfinder)
3.2 lb / 1.45 kg (body only)
2.29 lb / 1.04 kg (Gimbal)
