ARRI ALEXA 35 XTREME Premium Body & PL Mount Set

Audio Input & Output

1x 1/8" / 3.5 mm TRRS Headphone/Mic Headphone Output
1x 6-Pin LEMO Line Input

Media Slot

Single Slot: Codex Compact Drive

Battery Type

B-Mount

Power Input & Output

1x LEMO 8-Pin (20.5 to 33.6VDC) Input

Other Input & Output

2x CoaXPress Viewfinder
1x LEMO 4-Pin Control Input/Output
1x LEMO 4-Pin (Serial) Data Input/Output
1x LEMO 5-Pin (Timecode) Input/Output
1x LEMO 10-Pin (Ethernet) Control
1x BNC (Sync) Input/Output
1x USB-C Data Input/Output
1x Pogo 5-Pin
1x pogo 18-Pin

Wireless Control

802.11b/g Wi-Fi

Material

Aluminum

Dimensions

8 x 6 x 5.8" / 203 x 152.5 x 147 mm

Weight

6.4 lb / 2.9 kg (With Antennae)
