Pixels Per Inch

323 ppi

Image Control

Anamorphic De-Squeeze, Check Field, Customizable Aspect Ratios, False Color, Focus Peaking, Histogram, Image Flip, Image Freeze, Overscan, Screen Markers, Vectorscope, Waveform

Audio Input & Output

1x 1/8" / 3.5 mm Headphone Output

Embedded Audio

HDMI

Video Format

HDMI
DCI 4K: 60/59.94/50/48/47.95/30/29.97/25/24/23.98
UHD 4K: 60/59.94/50/48/47.95/30/29.97/25/24/23.98
1080p: 60/59.94/50/30/29.97/25/24/23.98
1080i: 60/59.94/50
720p: 60/59.94/50
576p
576i
480p
480i

Mount

1x Anti-Twist 1/4"-20 Female (top)
1x Anti-Twist 1/4"-20 Female (right)
1x Anti-Twist 1/4"-20 Female (bottom)

Media Slot

Single Slot: microSD (Unspecified Type, LUT/Firmware Update Only)

Battery Type

1x L-Series

Power Input & Output

1x Barrel 5.5 mm (12 VDC) Input
1x USB-C (2 A / 5 VDC) Input
1x Barrel 5.5 mm (8 VDC) Output

Other Input & Output

No

Wi-Fi Compatibility

No

Bluetooth Compatibility

No

Input Power

7 - 24 VDC

Dimensions

7.3 x 4.6 x 0.8" / 186 x 117 x 21 mm

Weight

20.9 lb / 9.5 kg
