Atomos Ninja TX 5.2" Camera to Cloud Monitor/Recorder

Image Control

Anamorphic
De-Squeeze, Blue Only, False Color, Focus Peaking, Image Flip, OSD
Flip, RGB Parade, Screen Markers, Vectorscope, Waveform, Zebra

Audio Input & Output

1x 1/8" / 3.5 mm Input
1x 1/8" / 3.5 mm Headphone Output

Embedded Audio

HDMI/IP/NDI/SDI/USB

Video Format

HDMI (8/10/16-Bit 4:2:2)
8K Raw: 30
6K Raw: 60
3.5K Raw: 60
DCI 4K: 60/59.94/50/30/29.97/25/24/23.98
UHD 4K: 60/59.94/50/30/29.97/25/24/23.98
1080p: 120/100/60/59.94/50/30/29.97/25/24/23.98
1080PsF
1080i: 60/59.94/50
720p: 60/59.94/50

Media Slot

Single Slot: CFexpress Type B [Record/LUT/Firmware]

Battery Type

1x L-Series Mount on Fixed Plate

Power Input & Output

1x USB-C (16.8 VDC) Input

Other Input & Output

2x USB-C Input/Output [Shared with Firmware/LUT Upload/Record/Power]
1x 2.5 mm (LANC) Input

Wi-Fi Compatibility

Wi-Fi 6E (802.11ax)

Bluetooth Compatibility

Yes

Material

Aluminum, Plastic

Input Power

6.2 - 16.8 VDC

Dimensions

5.9 x 3.6 x 1.4" / 151 x 92 x 36 mm

Weight

14.1 oz / 400.00 g
